3.6/6 kW integrated solar-storage system

A vertical, all-in-one energy storage unit integrating a hybrid inverter, an MPPT solar controller and a lithium iron phosphate battery. The unit outputs pure sine wave AC power, features built-in multi-channel MPPT modules, is equipped with long-life lithium iron phosphate batteries, includes a battery balancing function, and offers optional Wi-Fi remote monitoring.
CONTACT US

Product Details

 Product Specifications
Model SW-3.6KW SW-6KW
Rated Power 3600W 6000W
LifePO4 Battery Specification 25.6V-206AH 25.6V-314AH 51.2V-166AH 51.2V-206AH 51.2V-314AH
Battery Capacity 5273WH 8038WH 8499WH 10547WH 16076WH
Stacking Quantity built-in
MPPT Input Max PV Input 5000W 9000W
PV Input Voltage 40~430VDC 60~450VDC
Max Open Circuit Voltage 450VDC 500VDC
Charging Current(can be set) 100A 120A
AC Input Voltage Ramge UPS 170~280VAC 170~264VAC
INV 90~280VAC 90~280VAC
Frequency 45~65Hz
Charging Current(can be set) 100A 120A
Inverter Output Voltage Range(can be set) 208/220/230/240VAC±5%
Frequency 50/60Hz
Output Wave Pure Sine Wave
Conversation Time 10ms
Efficiency >93% >94%
Overload 102~110%/60s;110%~130%/10s;130%~150%/3s;>150%/0.2s
Ambient Temperature For Operation -10~50℃
Ambient Temperature For Storage -15~60℃
Operating/Storage Environment 5~95%Relative humidity(non-condensing)
The company reserves the right to change without notice.
